Port Mirroring on a Cisco 3550 Switch

By Daniel Miessler on December 17th, 2007: Tagged as Networking

Just for reference…

Source port(s):

Switch# config t
Switch(config)# monitor session 1 source interface fastethernet 0/1
Switch(config)# monitor session 1 source interface fastethernet 0/2
Switch(config)# monitor session 1 source interface fastethernet 0/3
Switch(config)# monitor session 1 source interface fastethernet 0/4
(however many you want to monitor)

Destination port:

Switch(config)# monitor session 1 destination interface fastethernet 0/24

…then exit and:

Switch# show monitor session 1

It’ll show you what all ports are being monitored (sources) and what port to sniff on (destination). Fin.:

  • Saul Lethbridge

    4 Fa ports going out 1 Fa port…any dropped packets!!

  • Saul Lethbridge

    4 Fa ports going out 1 Fa port…any dropped packets!!

  • ghost16825
  • ghost16825
  • Saul Lethbridge

    I know this is just a reference, but I personally would be very concerned with sending more than a few Fa ports out a single Gi port, considering aggregate traffic. 4 fully saturated Fa ports = 800 Mb.

    The tao article above is also something to consider, very good info.

  • Saul Lethbridge

    I know this is just a reference, but I personally would be very concerned with sending more than a few Fa ports out a single Gi port, considering aggregate traffic. 4 fully saturated Fa ports = 800 Mb.

    The tao article above is also something to consider, very good info.

  • http://maxolasersquad.com/ Maxo

    I took the CCNA 1-4 (class, not the actual test.) As much as I love networking, that class let me know that I should not pursue a career in it.

  • http://maxolasersquad.com/ Maxo

    I took the CCNA 1-4 (class, not the actual test.) As much as I love networking, that class let me know that I should not pursue a career in it.

  • http://dmiessler.com/ Daniel Miessler

    I agree, guys. The place I implemented this had very little traffic on each port, and even then I realize it’s not ideal.

    The problem is that I need to monitor this network, not just a particular port. At the same client I have a number of taps in place (permanent fixtures that I had them buy) to facilitate ongoing traffic monitoring. I do recognize that this method is superior; it’s just that it doesn’t let you monitor everything on a low-traffic switch like a span does.

    The problem with the span, of course, is that at any time one or more of the ports being monitored could become NOT low-traffic, at which point the solution falls apart.

    At any rate, the post was for remembering syntax for the monitor command more than anything. Good discussion, though.

  • http://dmiessler.com Daniel Miessler

    I agree, guys. The place I implemented this had very little traffic on each port, and even then I realize it’s not ideal.

    The problem is that I need to monitor this network, not just a particular port. At the same client I have a number of taps in place (permanent fixtures that I had them buy) to facilitate ongoing traffic monitoring. I do recognize that this method is superior; it’s just that it doesn’t let you monitor everything on a low-traffic switch like a span does.

    The problem with the span, of course, is that at any time one or more of the ports being monitored could become NOT low-traffic, at which point the solution falls apart.

    At any rate, the post was for remembering syntax for the monitor command more than anything. Good discussion, though.
